Rekon 3 Nano Long Range Frame

Product Name:Rekon3 Long Range Frame Kit

Model:Rekon3 Frame Kit

Material:3K carbon fibre

Type:3-inch Frame

Wheelbase:140mm

Size:130*125mm

Front arm:2mm

Rear arm:2mm

PETG base plate

PETG middle plate

18650 battery box

Flight control installation hole:25.5x25.5mm

Support camera:14mm

Weight:23g

Package list:

1x 2mm front arm

1x 2mm rear arm

1x PETG base plate

1x PETG medium plate

1x 18650 battery box

4x round head screws M2*9

2x round head screws M2*6

2x cup head screws M2*3

10x round head tapping screws M2*8

6x M2 self tightening nuts

4x M2*6.6 shock absorption balls

Recommended parts:(not included)

Flight control:5A_ AIO

Motor:1202.5

Camera:14x14mm

Propeller:3 inches

Battery:18650-3000mah
